CAEPIPE 3D+

What's New in Version?
15.10

Release date: August 27, 2026

CAEPIPE and CAEPIPE 3D+ Version 15.10

Download pdf

15

Enhancements

5

Bug Fixes

5

Latest Standards

Beyond-Earth Analysis, Revit Integration and Buried Piping Calculations

CAEPIPE and CAEPIPE 3D+ Version 15.10

Key highlights include support for varying gravitational conditions in space and planetary environments, ASME B31.9 (2025), optional ASME B31J-based SIF calculations, a new Autodesk Revit Add-In, optional ALA 2001 buried piping calculations, and a sustained load case for improved support evaluation. Additional improvements include enhanced visualization, reporting, mesh refinement, model validation, and PCF interoperability, delivering greater accuracy, reliability, and efficiency across aerospace, industrial, energy, and infrastructure applications.

Learn More Enhancements Bug Corrections

Enhancement

Enhancements

Learn More

Bug

Bug Corrections

Nodal Mesh Refinement

While refining the nodal mesh for “Buried Piping” or “Dynamic Analysis,” the program was inserting rows that lacked node numbers and offset values (DX, DY, and DZ) whenever the newly generated node number exceeded 99999.

User Interface and Reports

• Merging the models that contain multi-level/uniform response spectrum with the same spectrum name in both the stress models was issuing "Access Violation". • Axial force and Bolt Circle data are not shown in Flange Report Display and Output to Printer when the Flange Equivalent Pressure is computed as per EN 13480-3. • Additional Weight input in the Load is not printed properly in the output (TXT and Hardcopy Print). • Opening the results file multiple times without closing CAEPIPE caused the Resultant Force and Resultant Moment values in the Nozzle Support Load Summary to change unpredictably. The reported values now remain consistent regardless of how many times the results file is opened.
