CAEPIPE Modeling
CAEPIPE helps you to rapidly design and analyze piping systems of any complexity with the least effort. It continues to be the easiest, fastest, most cost-effective, feature-rich and technologically peerless software tool in the pipe stress software market.
Features Unique to CAEPIPE
Supported Piping Codes & Standards
Synchronized Highlight (in all open windows) for easier pinpointing of nodes, elements and other items. Eliminates confusion and helps you to focus on the issue.
Dynamic updating of data across all windows (make one change in one window and all other windows reflect the change). Fewer keystrokes and mouse movements to go through; Flexibility and instant visual feedback.
Advanced MS-Windows technology for fast operation (memory mapped files, intelligent repainting, multithreading etc.). Results in extremely fast operation, and quick analysis times.
Multiple open windows providing simultaneous visual and textual feedback on different aspects of the model. Aids rapid and accurate understanding of model details and its response to loadings.
Single-click editing in Graphics window for alternative modeling. Two ways of editing model (not forced to textual screen editing only).
Pipes, Elements, Components and Supports
Pipes, Elements, Components and Supports
Supports & Restraints
Model tie rods with different stiffnesses and gaps in tension/compression.
Support types include anchor blocks, spring hangers, clevis hangers, rod hangers, guide/pipe slide assemblies and more.
Component Libraries and Analysis
Locate nodes in the model instantly using search node feature.
Built-in SIF libraries from ASME B31.x, ASME Section III and European EN codes.
Option to compute SIFs and Flexibility Factors using ASME B31J.
Model gaps using limit stops and friction at supports.
Ability to model supports connected to other nodes.
Pipes & Elements
Model straight pipes, elbows, bends, valves, concentric and eccentric reducers, tees, miters, rigid elements and more.
Model expansion joints such as slip, ball, hinge, bellows, gimbal, and universal joints.
Model Jacketed pipes and jacketed bends with separate temperatures and pressures.
Model cold springs, cut short or cut long.
Model beams and support structures with beta angles and end releases.
Libraries & Analysis
Component Libraries and Analysis
Locate nodes in the model instantly using search node feature.
Built-in SIF libraries from ASME B31.x, ASME Section III and European EN codes.
Option to compute SIFs and Flexibility Factors using ASME B31J.
Model gaps using limit stops and friction at supports.
Ability to model supports connected to other nodes.
Powerful Features and Capabilities
Full Mouse Support - The Way You Expect
Graphics Highlighting
Use this feature to pinpoint any component, view branch lines only.
.jpg)
Simple and Elegant User Interface
Simple and Elegant User Interface
CAEPIPE has a well-designed user interface with drop down menus and descriptive dialog boxes that make for efficient modeling sessions.
Powerful Features and Capabilities
Caepipe Fast Efficient Analysis
Easy and Flexible Structural Modeling (AISC/user definable libraries)
Built-in code libraries for SIFs
Built-in libraries for pipe sizes, materials, valves etc.
Nonlinear analysis: Gaps and Friction
Itemized Listings: For Quick Review and Editing
Simultaneous Error-checking
Use Any Combination of Units (SI/Metric/English)
